HYPILE’s Steel Pipe Piles are engineered to provide exceptional load-bearing capacity and long-term durability in challenging geotechnical environments. Ideal for deep foundations, marine structures, and heavy-load infrastructure, our piles combine advanced steel grades, precision manufacturing, and corrosion-resistant coatings to ensure reliable performance in soil, water, and industrial settings.

Manufacturing Process：

SEAMLESS , SSAW, LSAW and Roller Welded

Steel Standards & Grades:

Chinese Grade: Q235, Q355, Q390, Q420, Q460, Q550, Q620, Q690, Delivery Condition: N, M, Quality Class: B, C, D, E

API 5L PSL1 / PSL2: GR B , X42, X46, X52, X56, X60, X65, X70 , X80

ASTM A252 GR 1, GR 2, GR 3

ASTM A500: GR A, GR B, GR C, GR D

ASTM A53: GR A, GR B, GR C

ASTM A572 GR 42, 50, 55, 60, 65

ASTM A709 GR 36, 50, QST 50/50S/65/70, 50S/50W/50CR. HPS 50W /70W / 100W

ASTM A588

EN 10219: S235, S275, S355,S460 Series, Delivery Condition: N, M, Quality Class: JRH, J0H, J2H, MH, MLH, NH, NLH....

Dimensional Specifications

Outer Diameter (OD):168.3 mm –4064mm (6" – 160")

Wall Thickness (WT): 3mm – 120 mm

Length: Up to 100 meters

Applications

Deep Foundations: High-rise buildings, bridges, and industrial facilities.

Marine Structures: Offshore platforms, jetties, and wind turbine foundations.

Geotechnical Solutions: Soil stabilization, slope reinforcement, and seismic retrofitting.

Infrastructure: Ports, railways, and heavy-load transportation hubs.

‌Certifications & Quality Assurance‌

‌Certifications‌: ISO 9001:2015, API 2B/5L, CE

‌Third-Party Inspections‌: Lloyd’s Register, DNV GL, SGS, Bureau Veritas,etc....
